1. Hydrostatic transmission system, can use different type attachments and for many kinds of work.
2. With small size, 360° degrees steering, it can work flexibly in anywhere, even narrow condition.
3. American Briggs & Stratton or Kohler gasoline engine, without any emission standard and 3 years warranty.
4. Italian Hydro control valve make the quality reliable.
Rated Speed
3300rpmOperating Weight
890kgStandard Bucket Capacity
0.15m³1. Hydrostatic transmission system, can use different type attachments and for many kinds of work.
2. With small size, 360° degrees steering, it can work flexibly in anywhere, even narrow condition.
3. American Briggs & Stratton or Kohler gasoline engine, without any emission standard and 3 years warranty.
4. Italian Hydro control valve make the quality reliable.
Max Working Height | 2128mm |
Max Pin Height | 1869mm |
Max Dump Height | 1473mm |
The Highest Unload Distance | 399mm |
Bucket Swing Angle | -- |
Bucket Unloading Angle | 30° |
Opening-Closing Angle | -- |
Angle Of Departure | 10° |
Total Height | 1218mm |
The Height From The Ground | 105mm |
Wheelbase | -- |
No Bucket Length | 1752mm |
Total Length with Bucket | 2206mm |
Total Width | 1060mm |
Bucket Width | 980mm |
Turning Radius | 1317mm |
Rated Power | 15.4kW(21hp) |
Rated Speed | 3300rpm |
Noise | 95Db |
Hydraulic Pressure | 17MPa |
Max Lifting Force | 375 kg |
Bucket Capacity | 0.15 m³ |
Max Lifting Power | 827LB |
Speed | 0-5.5km/h |
Operating Weight | 890 kg |
