1. Small size and easy to transport, could be loaded onto the light truck or small trailer, two sets could be loaded into one 20GP container to save freight cost.
2. Special design on separating engine and radiation space, using an enhanced cooling fan to increase cooling efficiency.
3. Famous brand hydraulic system parts ensure stable quality.
4. Equipped with double fuel filter to guarantee fuel purity to protect the engine.
5. Boom deflection design meet narrow work condition, reinforced rubber track to protect road.
6. Extend hydraulic line for various attachments.
7. Comfort seats make operator easy to work.
Maximum Engine Power
22.1kWOperating Weight
2200kgStandard Bucket Capacity
0.1m³1. Small size and easy to transport, could be loaded onto light truck or small trailer, two sets could be loaded into one 20GP container to save freight cost.
2. Special design on separating engine and radiation space, using enhanced cooling fan to increase cooling efficiency
3. Famous brand hydraulic system parts ensure the stable quality.
4. Equipped with double fuel filter to guarantee fuel purity to protect engine
5. Boom deflection design meet narrow work condition, reinforced rubber track to protect road
6. Extend hydraulic line for various attachments.
7. Comfort seat make operator easy to work.
| Term No. | ERE25 |
| Model | Laidong 3TE30 22.1kW/2200rpm |
| Type | Eletronic injection, water cooled, natural intake |
| No. of Cylinder | 3 |
| Swing Speed | 12-14r/min |
| Traveling Speed | 2.8km/h |
| Grade Ability | 70(35°) % |
| Traveling Tracking Force | 15kN |
| Bucket Digging Force | 11.5kN |
| Arm Digging ForceArm Digging Force | 9.3kN |
| Hydraulic System working pressure | 16MPa |
| Hydraulic Pump | AHWY Gear Pump |
| Hydraulic pump flow | 2×12+5 L/min |
| Swing Motor | Eaton |
| Traveling Motor | Eaton |
| Fuel Tank Capacity | 26L |
| Hydraulic Tank Capacity | 27L |
| Overall Length | 4080mm |
| Overall Width | 1300mm |
| Overall Height | 2280mm |
| Ground Clearance | 490mm |
| Track Length | 1630mm |
| Track Width | 250mm |
| Undercarriage Width | 1270mm |
| Undercarriage Ground Clearance | 235mm |
| Dozer Blade | 1270×240mm |
| Operation Weight | 2200kg |
| Bucket Capacity | 0.1m³ |
| Max. Digging Radius | 4350mm |
| Max. Digging Depth | 2450mm |
| Max. Digging Height | 3700mm |
| Max. Dumping Height | 2330mm |
| Max. Dozer Cutting | 310mm |
| Max. Dozer Lifting | 240mm |
| Boom Deflexion (Left/Right) | 70/50° |
| Tail Swing Radius | 1180mm |
| Front Min. Swing Radius | 2020mm |
