1. Cummins Engine with six cylinders ensure the power.
2. Famous brand hydraulic system parts ensure the stable quality.
3. Equipped with double fuel filter to guarantee fuel purity to protect engine.
4. Extend hydraulic line for various attachments.
5. Comfort cabin, wide and open sight make operator easy to work.
6. Special design on separating engine and radiation space, using enhanced cooling fan to increase cooling efficiency.
7. Imported pilot control joystick make your operation easy & joyful.
8. Strong structural parts make sure the working quality duration.
Bucket Capacity
1.1m³Net Weight
23000kgEngine Power
133kW1. Cummins Engine with six cylinders ensure the power.
2. Famous brand hydraulic system parts ensure the stable quality.
3. Equipped with double fuel filter to guarantee fuel purity to protect engine.
4. Extend hydraulic line for various attachments.
5. Comfort cabin, wide and open sight make operator easy to work.
6. Special design on separating engine and radiation space, using enhanced cooling fan to increase cooling efficiency.
7. Imported pilot control joystick make your operation easy & joyful.
8. Strong structural parts make sure the working quality duration.
| Term No. | ERE230 |
| Model | Cummins QSB7 124kW/2050rpm |
| Type | Electronic injection, water cooled, supercharge |
| Swing Speed | 0-13r/min |
| Traveling Speed | 2.8-4.2 km/h |
| Hydraulic Pump | PNM |
| Hydraulic Valve | Parker |
| Swing Motor | Strong(Sunjin) |
| Traveling Motor | Doosan |
| Overall Length | 9565mm |
| Overall Width | 2990mm |
| Overall Height | 3000mm |
| Boom Length | 5700mm |
| Arm Length | 2920mm |
| Track width | 600mm |
| Operation Weight | 23000kg |
| Bucket Capacity | 1.1m³ |
| Max. Digging Radius | 9936mm |
| Max. Digging Depth | 6550mm |
| Max. Digging Height | 9680mm |
