1.Hydrostatic transmission system,can use different attachments and for many kinds of work.
2.With small size,360 degrees steering, it can work flexibly anywhere,even narrow condition.
3.American Briggs & Stratton engine, meets any emission standard and 3 years warranty.
4.Italian hydro control valve makes the quality reliable.
Rated Operating Capacity
200kgBucket Capacity
0.12m³Total Height
1309mm1.Hydrostatic transmission system,can use different attachments and for many kinds of work.
2.With small size,360 degrees steering, it can work flexibly anywhere,even narrow condition.
3.American Briggs & Stratton engine, meets any emission standard and 3 years warranty.
4.Italian hydro control valve makes the quality reliable.
| Max Working Height | 2065mm |
| Max Pin Height | 1803mm |
| Max Dump Height | 1386mm |
| The Highest Unload Distance | 471mm |
| Bucket Swing Angle | -- |
| Bucket Unloading Angle | 32° |
| Opening-Closing Angle | -- |
| Angle Of Departure | 18° |
| Total Height | 1309mm |
| The Height From The Ground | 123mm |
| Wheelbase | 690mm |
| No Bucket Length | -- |
| Total Length (With Bucket ) | 2210mm |
| Total Width | 800mm |
| Bucket Width | 820mm |
| Turning Radius | 1236mm |
| Rated Power | 21HP/23HP |
| Rated Speed | 3600rpm |
| Noise | ≤95Db |
| Hydraulic System | 17MPa |
| Max Lifting Force | 375kg |
| Bucket Capacity | 0.12m³ |
| Max Lifting Power | 827Lb |
| Speed | 5.5km/h |
| Operating Weight | 855kg |
