1.Hydrostatic transmission system,can use different attachments and for many kinds of work.
2.360 degrees steering, it can work flexibly anywhere,even narrow condition.
3.Adapt hydraulic leveling system, can keep the bucket balance during lifting and down.
4.This model adapts rubber track driving system, suitable for soft road and terrain. With variable speed motor, max speed can achieve 18km/h.
Rated Power
74kWBucket Capacity
0.55m³Operation Load
1500kg1.Hydrostatic transmission system,can use different attachments and for many kinds of work.
2.360 degrees steering, it can work flexibly anywhere,even narrow condition.
3.Adapt hydraulic leveling system, can keep the bucket balance during lifting and down.
4.This model adapts rubber track driving system, suitable for soft road and terrain. With variable speed motor, max speed can achieve 18km/h.
| Operating Load | 1500kg |
| Max Speed | 12/18km/h |
| Rated Flux | 88L/min |
| Rated Power | 74kW(WEICHAI) |
| Fuel Tank Capacity | 90L |
| Bucket Capacity | 0.55mm³ |
| Overall Operating Height | 4170mm |
| Height to Bucket Hinge Pin | 3150mm |
| Height To Top Of Cab | 2160mm |
| Height To Bottom Of Level Bucket | 2983mm |
| Without Bucket Length | 3000mm |
| Overall Length With Bucket | 3700mm |
| Dumping Angle At Maximum Height | 40° |
| Dumping Height | 2450mm |
| Dumping Reach | 700mm |
| Rollback Of Bucket On Ground | 30° |
| Rollback Of Bucket At Full Height | 104° |
| Wheelbase | 1500mm |
| Ground Clearance | 200mm |
| Angle Of Departure | 20° |
| Front Turning Radius Without Bucket | 1365mm |
| Rear Axle To Bumper | 938mm |
| Tread Width | 1654mm |
| Width | 1994mm |
| Bucket Width | 2030mm |
| High Flow Flux | 140L/min |
