1. The frame of the high strength adapts to the heavy load condition;
2. Working mechanism lightens the unloading impact greatly;
3.Hydraulic wet brake ensures the safe and reliable operation and travelling;
4. Support design to raise boom length.
Rated Power
76kWNet Weight
5300kgBucket Capacity
1m³1. The frame of the high strength adapts to the heavy load condition;
2. Working mechanism lightens the unloading impact greatly;
3.Hydraulic wet brake ensures the safe and reliable operation and travelling;
4. Support design to raise boom length.
| Net Weight | 5300kg |
| Rated bucket capacity | 1m³ |
| Rated power | 76kw--2400r/min |
| Maximum tractive force | 60KN |
| Maximum breakout force | ≥70KN |
| Model | YN 4102 turbo engine |
| Track Base | 1510mm |
| Maximum grade ability | 30º |
| Maximum dump height | 3200mm |
| Maximum dump reach | 1050m |
| Overall dimension (L×W×H) | 5870×2080×2870mm |
| Minimum turning radius | 5600mm |
| Maximum speed | 30km/h |
| Drive axles model | medium wheel reduction axle |
| Wheel base (mm) | 2460mm |
| System working pressure | 16MPa |
| bucket lifting time | ≤6s |
| bucket falling time | ≤4.5s |
| Total time for a single working cycle | ≤11.5s |
| Type specification | 16/70-20 |
