1. 2.0 ton loading capacity
2. Chinese famous brand Yunnei 490 (YN27,42kw) engine
3. 8 gear shift, max driving speed can reach 33km/h
4. 16/70-20 bigger tyre
5. Cabin with skylight and side window, same design as Caterpillar
6. New engine cover
Engine Power
42kWOperating Weight
1800kgBucket Capacity
0.6m³1. 2.0 ton loading capacity
2. Chinese famous brand Yunnei 490 (YN27,42kw) engine
3. 8 gear shift, max driving speed can reach 33km/h
4. 16/70-20 bigger tyre
5. Cabin with skylight and side window, same design as Caterpillar
6. New engine cover
Term No. | ER920 |
Max Loading Capacity | 1800kg |
Bucket Capacity | 0.6m³ |
Lifting Height | 4220mm |
Dumping Height(At dumping Angle at 45°) | 3300mm |
Dumping Distance | 760mm |
Pin Height | 3720mm |
Max. Driving Speed | 5-28km/h |
Max. Traction | 35kN |
Max Digging Force | 33kN |
Digging Depth | 100mm |
Greadeability | 25° |
Max. Steering Angle | 35° |
Min.Turning Radius | 6000mm |
Overall Length(With Bucket on Ground) | 5360mm |
Bucket Width(Overall Width) | 1800mm |
Overall Height | 2740mm |
Wheel Base | 2240mm |
Track Base | 1510mm |
Min. Ground Clearance | 300mm |
Net Weight | 4200kg |
Engine Model | YUNNEI 490 (YN27) |
Emission Standard | Nationa lⅡ |
Rated Power | 42kw |
Rated Speed | 2400r/min |
