1. Torch brand battery which is the number one battery in China. Long service life.
2. Adjustable seat with safe belt for comfortable and safe to drive.
3. New design frame with wide view. No blind spots.
4. World famous brand controller.
Pump Power
13ACkWRated Load
3000kgWheel Base
1680mm1. Torch brand battery which is the number one battery in China. Long service life.
2. Adjustable seat with safe belt for comfortable and safe to drive.
3. New design frame with wide view. No blind spots.
4. World famous brand controller.
| Power Type | Battery |
| Rated Load | 3000kg |
| Load Center DIstance | 500mm |
| Driving Type | Seat |
| Length With Fork | 3630mm |
| Length Without Fork | 2570mm |
| Whole Width | 1243mm |
| Fork Changing | 1060/250mm |
| Min Turning Radius | 2200mm |
| Frame Angle | 6°/12° |
| Max Lifting Speed Without Goods | 450mm/s |
| Max Lifting Speed With Full Goods | 280mm/s |
| Max Speed Without Goods | 14km/h |
| Max Speed With Full Goods | 12.5km/h |
| Wheel Base | 1680mm |
| Max Climbing Angle | ≤15% |
| Whole Weight | 4950kg |
| Driving Wheel | 2x/2 |
| Type Model | Solid Tyre |
| Front Tire | 28x9-15 |
| Pump Power | 13AC kW |
| Rear Type | 18x7-8 |
| Hand Brake | Hydraulic Pedal |
| Brake Type | M-Hand |
| Battery Volt/Capacity | 80V/500Ah |
| Driving Motor Power | 16.6AC kW |
| Height No Lifting Frame | 2070mm |
| Top Frame Height | 2210mm |
| Max Height Working | 4225mm |
| Distance From Seat To Top Light | 1060mm |
| Min Right Angle Aisle Width | 4100mm |
| Front Overhang | 490mm |
| Back Overhang | 425mm |
| Front Wheel Tread | 1000mm |
| Back Wheel Tread | 980mm |
| Min Floor Clearance | 135mm |
| Max Lifting Height | 3000mm |
| Free Lifting Height | 160mm |
